Brushless DC Pumps with Smart Control The era of smart refrigerant evacuation begins here with the combination of inverter, vacuum measurement and smart control in one unit. The light-weight, inverter-driven, dual-stage vacuum pump delivers high-speed evacuation along with high ultimate vacuum. Vacuum measurement technology precisely measures the system pressure. A digital display provides a comprehensive view of the system’s internal vacuum condition. Smart control assures the system’s vacuum by automatically extending the evacuation time after the system reaches the preset vacuum level. A built-in solenoid valve prevents oil back flow and seals the system to preserve the vacuum during power outage or accidental disconnect. Upon completion of operation, the unit will beep to remind the technician that evacuation is complete, so they can move on to the next job. Leading Technology, Superior Quality, Best Experience. Empowering you to work smarter! Model NRP6Di NRP8Di Power Supply V/Hz 115V / 60Hz 115V / 60Hz Flow Rate CFM 6 8 RLA A 5.5 6 Ultimate Vacuum micron 15 15 Pump Design Dual stage Dual stage Motor Power Hp 3/4 3/4 Inlet Ports 1/4″, 3/8″,1/2″ Flare 1/4″, 3/8″, 1/2″ Flare Oil Capacity oz 17.6 17.6 Dimensions in 14×5.3×11.9 14×5.3×11.9 Weight lbs 25.35 25.35 Warranty year 2 2 Warning: Do not leave pump running unattended in a closed environment without adequate ventilation. /wp-content/uploads/2019/02/NRP8Di.mp4
