General specifications Product Name Eaton 5PX Gen2 UPS Catalog Number 5PX1000IRT2UG2 UPC 743172104731 Product Length/Depth 448 mm Product Height 85.5 mm Product Width 438 mm Product Weight 19.6 kg Warranty 3 year on electronics, 2 year on battery Compliances IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 RoHS Compliant REACH UL 1778 CSA 22.2 Certifications CE cTUVus EAC Cm UKCA Ukr ENERGY STAR certified Model Code Eaton 5PX 1000i RT2U G2 Additional information Construction type 482.6 mm (19 inch) device Package contents Rack-mounting kit (2) Supports for tower mounting Cable locking system USB cable Serial cable (2) IEC-IEC cables Quickstart guide Safety instructions Phase (output) 1 Auto shutdown function Yes Color Black/silver Efficiency at max. load 98 Rack mounting kit Yes Phase (input) 1 Battery Battery type Lead-acid maintenance-free (replaceable) Runtime graph Battery replacement User replaceable Battery quantity 4 Battery management ABM & Temperature compensated charging method (user selectable), Automatic battery test, deep discharge protection, automatic recognition of external battery units Battery rating 12 V / 7 Ah Extended battery capability Yes Communication Includes network card No Communication USB port (HID compliant) Serial port (RS232) Mini-terminal block for remote On/Off and Remote Power Off Mini-terminal block for output relay Dry contacts (3 outputs, 1 input, optocoupler, DB9) User interface Multilingual graphical LCD display Potential free switch contact Yes Expansion slots One slot for optional communication card Software compatibility Eaton Intelligent Power Manager, Eaton Intelligent Power Protector Type of interface Other Electrical input Input connection C14 Input nominal voltage 230V default (200/208/220/230/240V) Nominal frequency 50-60 Hz Additional informationBrandsEATONWeight: 19.6 kgDimensions: 44.8 × 43.8 × 8.6 cmDownload DatasheetDownload Datasheet Download
